| Concrete output/hr | 15 m 3 | 30 m3 | 45 m3 | 60 m3 |
Aggregate storage system |
In line Batching Plant | |||
Aggregate storage bins / capacity |
4 Bins / 3m3 |
|||
Sand vibrator for bin |
1 Vibrator |
|||
Aggregate weighing system |
Load cell base |
|||
Aggregate loading |
Conveyor or Skip hoist |
|||
Skip hoist Capacity |
0.25 CuM |
0.50 CuM |
0.75 CuM |
1.00 CuM |
Type of mixer |
PAN or Planetary or Twin shaft |
|||
Capacity of mixer |
0.25 CuM |
0.50 CuM |
0.75 CuM |
1.00 CuM |
liner Tiles of mixer |
Quard 500 |
|||
Door opening |
Pnumatics (Hydraulics optional) |
|||
Cement Storage
|
100 Ton silo |
100 Ton silo |
100 Ton silo |
100 Ton silo |
500 kg hoppe |
500 kg hoppe |
|||
Fly ash Storage
|
100 Ton silo |
100 Ton silo |
100 Ton silo |
100 Ton silo |
500 kg hoppe |
500 kg hoppe |
|||
Cement and flyash weighing |
load cell base |
load cell base |
load cell base |
load cell base |
Cement / fly ash vibrator for hopper |
1 Vibrator |
|||
Water measuring system |
Auto time basis (weight base optional) |
|||
Water pump |
1.0 Hp |
1.0 Hp |
1.5 Hp |
1.5 Hp |
Addmixture measuring system |
Auto time basis (weight base optional) |
|||
Addmixture pump |
60 watt |
60 watt |
120 watt |
120 watt |
Air compressor |
3HP |
|||
Control panel |
Fully auto |
|||
SCADA |
Yes |
|||
