Number of Bins |
1/2/3/4 As per agreegates Numbers. |
Bins Capacity |
3 CuM / 6 CuM / 7.5 CuM |
Wall Thickness |
04 mm Mild Steel |
Number of Loadcells |
04 / 06 As per number of bins |
Electronics Control |
PLC base fully automatic |
Weighing Accuracy |
98% weighing accuracy |
Motor for Conveyor |
05 / 7.5 Hp SIMENS |
Vibrator for Bin |
0.25 HP |
Conveyor Belt |
09 mm thick 750 wide |
Door Opening |
Pnumatic controled |
Recipe Storage
Number of concrete recipes can be store in controlling system
Working deta
Last 20,000 batch deta can be stored. Also can take in to USB.
Wall thickness
Bins wall are made up of 04 MM mild steel which become stronger with 100 x 50 chanel support
Custmization in bins
Number of bin and capacity of bins are to be customize as per requirments
Loading height
Loading height is standard for all batching plants. Designed height with
consideration of standard tractor loader height. Lower bin height with higher
capacity for easy loading. Batching plant loading option - with load or without loader
Transportation
Upper portion can be dismental and maintain height as per transportation rules.
Suaitable for container transportation.
Wall Vibrations
Vibrator provided for bin which contain wet material. With wall vibration wet material also discharge from bins. Extra vibrators can attached as per requirment
